Product Detail
Specs
1ch Passive
Video
Frequency respons: DC-6Mhz Common-mode/Differential-mode Rejection: 15khz -6Mhz 60dB type
Audio/data
NO
Power
NO
Impedance
Coax,male BNC:75Ohm UTP(Screwless)Terminal Block or
Wire type
One Unshielded Twisted Pair 24-16AWG(0.5-1.31mm) Per video signal:DC Loop Resistance 52 ohms per 1,000 ft(18 ohms per 100m)
Surge suppression
6000V
Control
NO
UTP Port
Terminal Block
Dimensions(mm)
32*21*15
Weigth(g)
18
Environment
Temperature:-10o -+50oC Humidity:0~95%
Warranty
1Y
