Product Detail
|
GENERAL
|
|
| Technology | 24-pin dot matrix |
| Resolution | 240 x 360 dpi |
| Fonts | OCR A-B, ROMAN, Sans Serif, Italic, Courier |
| Pitch | 10, 12, 15, 16.6, 17,1 cpi |
| Printing speed at 10 cpi | VHSD: 560 cps HSD: 510 cps Draft: 370 cps NLQ: 185 cps LQ: 125 cps BIM: 2000 dps |
| Line length | 238,76 mm (94 columns at 10 cpi) |
| Line spacing | 1/5", 1/6", n/216", n/240" |
| Copies | Original + 6 copies |
| Interfaces | Standard: RS232 serial, IEEE 1284 parallel and USB 2.0 Optional: expansion slot |
| Emulations | Olivetti Standard, IBM PP & X24 Optional: IBM 4722/9068 IBM PP & X24 WINCOR 4915 EPSON LQ 2550 UNISYS EFP series |
| Noise level | < 54 dBA (ISO 7779 with ECMA 132 text) |
| Document Handling | - Feed width: 245 mm - Completely flat paper feed - Automatic insertion with autoborder - Automatic document-thickness monitoring |
| Power consumption | Min. 6,5 W (9 W the scanner model) Max. 85 W (printing) |
| Ribbon cartridge | 10 million characters |
| Voltage | 230V / 50Hz 115V / 60Hz |
| Certifications & Regulatory | CE, TüV NRTL, FCC class A verified ENERGY STAR all models excluding versions with scanner |
| Options | MICR reader (CMC7, E13B) Scanner |
| Dimensions (WxDxH) | 384 x 296 x 204 mm 15.12" x 11.65" x 8.03" |
| Weight | 10.5 Kg |
