Product Detail
| Supported operating systems | Windows® 10 (32-bit/64-bit), Windows® 8.1 (32-bit/64-bit), Windows® 7 (32-bit/64-bit), Windows Server® 2019 (64-bit), Windows Server® 2016 (64-bit), Windows Server® 2012 R2 (64-bit), Windows Server® 2012 (64-bit), Windows Server® 2008 R2 (64-bit),Windows Server® 2008 (32-bit/64-bit), Linux (Ubuntu)(1) | |
|---|---|---|
| Scanner Type | ADF (Automatic Document Feeder) | |
| Scanning modes | Simplex / Duplex, Color / Grayscale / Monochrome | |
| Image Sensor Type | Single line CMOS-CIS x 2 (Front x 1, Back x 1) | |
| Light Source | R, G, B LED x 2 (Front x 1, Back x 1) | |
| Document size | Maximum: A4 Portrait (210 x 297 mm) or Legal (8.5 x 14 in.) or 8.5 x 34 in. (215.9 x 863.6 mm) (long page scanning: 3,048 mm (120 in.)) Minimum: A8 Portrait / Landscape (52 x 74 mm) |
|
| Paper weight (Thickness) |
Paper | 50 to 209 g/m2 (0.06 to 0.26 mm) * A8 size: 127 to 209 g/m2 (0.15 to 0.26 mm) |
| Plastic Card | ISO7810 ID-1 type compliant (0.76 mm or less, embossed plastic cards with total thickness of 1.24 mm or less) | |
| Scanning speed (A4, Portrait) (1) |
Color (2) | Simplex: 25 ppm (200 dpi / 300 dpi) Duplex: 50 ipm (200 dpi / 300 dpi) |
| Grayscale (2) | ||
| Monochrome | ||
| Paper chute capacity (A4 Landscape) (3) | 50 sheets (A4: 80 g/m2 or 20 lb) | |
| Expected Daily volume | 4,000 sheets | |
| Background colors | White (Hardware, scanned background is gray) | |
| Optical Resolution | 600 dpi | |
| Output Resolution (4) | Color (24-bit) | 50 dpi to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver) (5) |
| Grayscale (8-bit) | ||
| Monochrome (1-bit) | ||
| Output format | Color: 24-bit, Grayscale: 8-bit, Monochrome:1-bit | |
| Internal video processing | 65,536 levels (16-bit) | |
| Interface | USB2.0 | |
| Connector shape | B type | |
| Image processing function | Auto color detection, Automatic page size detection, De-Skew, Multi-image, Blank page skip, Error diffusion, Dropout color (R, G, B, Saturation), Image emphasis, Advanced DTC, sRGB, Halftone, Smoothing, Split image, Vertical streaks reduction, Digital endorser, Edge correction, Dynamic threshold(iDTC) | |
| Power requirement | AC 100 V to 240 V ± 10% | |
| Power consumption | Operating: 18 W or less Sleep mode: 1.6 W or less Auto standby (OFF) mode: 0.4 W or less |
|
| Operating environment | Temperature: 5 to 35 °C (41 to 95 °F) Relative humidity: 20 to 80% (Non-condensing) |
|
| Dimensions: Width x Depth x Height (6) | 298 mm x 135 mm x 133 mm (11.7 in. x 5.3 in. x 5.2 in.) | |
| Weight | 2.5 kg | |
| Included software / drivers | PaperStream IP (TWAIN / TWAIN x64 / ISIS) for SP Series (7), PaperStream Capture Lite(9), Software Operation Panel, Error Recovery Guide, Presto!™ PageManager™, ABBYY™ FineReader™ Sprint, Scanner Central Admin Agent | |
| Environmental compliance | ENERGY STAR® and RoHS | |
| Others | Multifeed detection | Yes (Standard) ultrasonic multifeed detection sensor x 1 |
| Long page scanning (8) | 3,048 mm (120 in.) | |
| Included items | AC adapter, USB cable, Setup DVD-ROM | |
