Product Detail
-
Output power capacity10.0 KWatts / 10.0 kVA
-
Max Configurable Power (Watts)10.0 KWatts / 10.0 kVA
-
Nominal Output Voltage230V
-
Output Voltage DistortionLess than 2%
-
Output Frequency (sync to mains)50/60Hz +/- 3 Hz
-
Other Output Voltages220, 240
-
Load Crest Factor3 : 1
-
TopologyDouble Conversion Online
-
Waveform typeSine wave
-
Output Connections(3) IEC Jumpers (Battery Backup)(6) IEC 320 C13 (Battery Backup)(1) Hard Wire 3-wire (H N + G) (Battery Backup)(4) IEC 320 C19 (Battery Backup)
-
BypassInternal Bypass (Automatic and Manual)
Input
-
Nominal Input Voltage230V , 400V 3PH
-
Input frequency40 - 70 Hz (auto sensing)
-
Input ConnectionsHard Wire 3 wire (1PH+N+G), Hard Wire 5-wire (3PH + N + G)
-
Input voltage range for main operations160 - 275V
-
Input voltage adjustable range for mains operation100 - 275 (half load), 173 - 476 (half load)V
-
Other Input Voltages220, 240, 380, 415
Batteries & Runtime
-
Battery typeMaintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
-
Typical recharge time1.5hour(s)
-
Replacement BatteryAPCRBC140
-
Expected Battery Life (years)3 - 5
-
RBC Quantity2
-
Extendable Run Time1
-
Extended Run OptionsAPC-Smart-UPS-SRT-10000VA-RM-230V
-
Runtime
-
Efficiency
Communications & Management
-
Interface Port(s)RJ-45 10/100 Base-T , RJ-45 Serial , Smart-Slot , USB
-
Control panelMulti-function LCD status and control console
-
Audible AlarmAudible and visible alarms prioritized by severity
-
Emergency Power Off (EPO)Yes
-
Available SmartSlot™ Interface Quantity1
Surge Protection and Filtering
-
Surge energy rating480Joules
Physical
-
Maximum Height263mm , 26.3CM
-
Maximum Width432mm , 43.2CM
-
Maximum Depth715mm , 71.5CM
-
Rack Height6U
-
Net Weight111.82KG
-
Shipping weight130.0KG
-
Shipping Height461mm , 46.1CM
-
Shipping Width600mm , 60.0CM
-
Shipping Depth1000mm , 100.0CM
-
ColorBlack
Environmental
-
Operating Temperature0 - 40 °C
-
Operating Relative Humidity0 - 95% non-condensing %
-
Operating Elevation0-3000meters
-
Storage Temperature-15 - 45 °C
-
Storage Relative Humidity0 - 95% non-condensing %
-
Storage Elevation0-15000meters
-
Audible noise at 1 meter from surface of unit55.0dBA
-
Online thermal dissipation1947.0BTU/hr
-
Protection ClassIP 20
Conformance
-
ApprovalsCE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, ENERGY STAR V1.0 (EU), IRAM, RCM, VDE
-
Standard warranty3 years repair or replace (excluding battery) and 2 years for battery
Sustainable Offer Status
-
RoHSCompliant
-
REACHREACH: Contains No SVHCs
-
Battery DirectiveCompliant
-
Battery Notests_Battery_Notes
