Feature |
AP, Bridge, Client, Repeater functions
WISP Client Router mode
WISP + Universal Repeater Mode
Detachable Antenna, 2 LAN ports
802.1x, WPA, WPA2 and Web Mgt.
TX power regulation in 4 levels
Watchdog function use PING
Wireless Client Isolation (e8 firmware)
ACK Timeout Adjustment
DHCP Relay function
802.11g Protection |
Hardware |
2 x 10/100Mbps LAN Port
2MB Flash, 16MB SDRAM
Reversed SMA Antenna Port
Power, LAN, WLAN LED indicators |
Antenna |
2 dBi detachable Dipole Antenna
Reversed SMA Connector |
Frequency Range |
USA (FCC) 11 Channels: 2.412GHz~2.462GHz
Europe (ETSI) 13 Channels : 2.412GHz~2.472GHz |
Rx Senstivity @ 25°C |
IEEE 802.11b |
Min (dBm) |
1Mbps |
-91 |
2Mbps |
-90 |
5Mbps |
-90 |
11Mbps |
-86 |
IEEE 802.11g |
Min (dBm) |
6Mbps |
-87 |
9Mbps |
-87 |
12Mbps |
-86 |
18Mbps |
-84 |
24Mbps |
-82 |
36Mbps |
-78 |
48Mbps |
-73 |
54Mbps |
-70 |
Modulation Technique |
11g Orthogonal Frequency Division Multiplexing (64QAM, 16QAM, QPSK,
BPSK)
11b Direct Sequence Spread Spectrum (CCK, DQPSK, DBPSK)
Data Rate: 54, 48, 36, 24, 18,11, 5.5, 2, 1 Mbps |
Output Power |
EU and FCC version
- 20dBm Max
- Adjustable in 6 levels
Brazil version
- 26dBm Max
- Adjustable in 8 levels |
WISP Mode |
DHCP, PPTP, L2TP, PPPoE ISP Authentication Support
Wireless Client function as WAN
WISP mode is not the same router mode
To configure the WISP mode, you PC must be connected to the LAN port |
Security |
64/128-bit WEP
WPA/WPA2-PSK support
802.1x Radius Support
WPA Enterprise support in AP/WDS mode |
Configuration |
Web Management
WDS (Bridge, Client, Repeater) mode
Hide ESSID
802.1x
MAC Access Control
MAC Access Table
Wireless Client Isolation (e8 firmware)
SSID, Channel, RTS Threshold, Frag Threshold |
Environmental |
Operating temperature: 0~60℃
Operating humidity (non-condensing): 20~80%
Storage temperature: -20~65℃
Storage humidity: 95% Max |
Power Supply |
DC12V |
EMI |
FCC, CE |
Product Weight (g) |
180 g |
Product Size
( L x W x H (mm) ) |
135 x 100 x 26mm |
