Product Detail
Model.
1500VA APC BR1500GI
Voltage.
230V
AC OUTPUT (Voltage).
865 Watts / 1500 VA
Nominal Input Voltage.
230V
Input Frequency.
50/60 Hz +/- 3 Hz (auto sensing)
Input Connections.
IEC-320 C14
Input voltage range for main.
176 - 294V
Input Breaker Capacity.
10.0 A
Battery Type.
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time.
8 hour(s)
Output Connections.
(5) IEC 320 C13 (Battery Backup)
(5) IEC 320 C13 (Surge Protection)
(2) IEC Jumpers (Battery Backup)
(5) IEC 320 C13 (Surge Protection)
(2) IEC Jumpers (Battery Backup)
Waveform Type.
Stepped approximation to a sinewave
Output Frequency (sync to mains).
